Product information:Aluminum composite panel is made of aluminum alloy and plastic
material to feature great hardness, light weight and smooth
service, provided with wide range of sizes, shapes, colors, and
styles to offer broader options for construction design, in a bid
to better meet the requirements of contemporary construction on
lightweight, elegant decoration and high hardness
Aluminum composite panel is widely used in all kinds of
architectural decorations for its excellent properties, such as
the, cladding, shops front, ceiling, counters, furniture, road
signs, billboards, kiosks, elevators, stores.
Product range:
| Surface Coating | Polyester Coating |
| Aluminum Alloy | AA1100, AA3003 |
| Aluminum Skin | 0.10mm,0.12mm,0.15mm,0.18mm,0.21mm,0.25mm,0.30mm |
| Panel Thickness | 2mm,3mm,4mm,5mm |
| Core Material | Non-toxic low density polyethylene |
| Panel Width | 1000mm,1220mm,1250mm,1500, |
| Panel Length | 2440mm,3050mm,4000mm,5000mm |
| Back Coat | PE coating, Primer Coating ,Mill finish |
Products tolerance:
| Panel Width | ±2mm |
| Panel Length | ±3mm |
| Panel Thickness | ±0.2mm |
| Panel Diagonal | ≤ 5mm |
| Aluminum layer thickness | ±0.02mm |
Technical data:
| Description | Test standard | Polyester |
| Coating Thickness (μm) | Polyester paint >=16μm | 16μm to 18μm |
| Coating flexibility (T-bend) | Polyester paint ≤ 3T | ≤ 3T |
| Color different | ΔE<=2.0 (follow color sample) | ΔE<=2.0 |
| Pencil hardness | >=HB | >=2H |
| Chemical resistance | 2%HCI or 2%NaOH test in 24 hours -No change | No change |
| Coating adhesion | >=1grade for 10810mm2 gridding test | 1grade |
| Resist solvent | 100 times without change | No change |
| Boiling water resistance | 2 hours without change | No change |
| Peeling strength/stripping strength | Average >=5N/mm of 180oc peel off
for panel with 0.21mm alu.skin | 5N/mm |
| Impact test for paint | 20KG.cm impact-paint no split for panel | No split |
| Abrasion resistance (L/Mil) | NIL | NIL |
| Temperature resistance | -40ºC to +80ºC temperature without
change of color difference
and paint peel off, peeling
strength average dropprate<=10% | Change of glossy only, no paint |
| Peel off |
| Coefficient of linear Thermal Expansion | 100ºC temperature difference | 2.4mm/n |
| Detergent resistance (3%) | ASTM D2248 | No change |
| Humidity Resistance (3000hrs,100%RH,100°F) | ASTM D2247 | No change |
| Salt spray resistance (3000hrs,5% salt) | ASTM B117 | No change |
| Resistance to Staining | 600h radiate in 800W/M2 in humidity condition
,glossiness deviation less grade 2,color difference <=4.0 | No change |
Company Information:
Henan Jixiang Industry Co., Ltd is located in Zhengzhou City,Henan
Province.
It is a professional company manufacturing high and new-tech
aluminum composite products,which is one of the earliest
manufacturers of aluminum composite in China.
Our company possesses 24 production lines and 6 coating lines for
aluminum composite panels whose annual output is 5.8million square
meters.
In addition, our company has passed ISO9001 International Quality
Management System Certification, ISO14000 Environment Management
System Certification, OHSAS18000 Occupation Health Safety
Management System Certification, and CTC Product Quality
Certification, and won several national patents.
Qurality certificate:
Exhibition &Customer:
Our products are accepted by markets widely with good performances
and brand image, which are sold around China and in more than 20
countries and regions, such as Southeast Asia, Africa, Australia,
America, and Brazil.
Why choose us:
- Scale : 24 advanced composite production lines and 6 aluminum coil
coating lines
- Quality: strictly comply with international standards and passed
ISO,SGS,CE,Rohs certificate etc.
- Experience : Founded in 1999, rich production experiences in
aluminum composite panel and well-known brand in China market.
- Lead Time: Absolute scale and experiences advantages ensure a
quality guaranteed order fast delivered to our customers.
- Superior ability of OEM Service.
- Multiple specs and colors for your choices, and customized color
acceptable.
